Model 2450

Interactive SourceMeter® Instrument Reference Manual Section 3:

Functions and features

2450-901-01 Rev. B/September 2013 3-105

Using a predefined trigger model

Before starting the trigger model, you need to set up your instrument for testing, including the source

and measurement settings. The trigger model will use these settings when making measurements.

Loading a predefined trigger model overwrites any existing trigger models.

Using the front panel:

1. Press the MENU key.

2. Under Trigger, select Templates.

3. Next to Trigger Model, select the trigger model template to use.

4. If the template you select has additional settings, you can use the default values or make any

necessary changes to the settings.

5. Select Generate.

6. Press TRIGGER to initiate the trigger model. The trigger mode indicator shows the status of the

trigger mode. See Trigger mode indicator (on page 2-16

) for descriptions of the indicators.

Using SCPI commands:

See the descriptions of the TRIGger:LOAD commands for details on how to format the command:

• :TRIGger:LOAD:CONFiguration:LIST (on page 6-161)

• :TRIGger:LOAD:EMPTy (on page 6-162)

• :TRIGger:LOAD:LOOP:DURation (on page 6-163)

• :TRIGger:LOAD:LOOP:SIMPle (on page 6-164)

• :TRIGger:LOAD:TRIGger:EXTernal (on page 6-165)

Using TSP commands:

See the descriptions of the trigger.model.load() command for details on how to format the

command:

• trigger.model.load() — Config List (on page 8-188)

• trigger.model.load() — Duration Loop (on page 8-189)

• trigger.model.load() — Empty (on page 8-190)

• trigger.model.load() — External Trigger (on page 8-190)

• trigger.model.load() — Simple Loop (on page 8-191)
