Keithley 2450 User Manual

Model 2450
Interactive SourceMeter® Instrument Reference Manual Section 2:
General operation
2450-901-01 Rev. B/September 2013 2-31
Template Description
Empty
Selecting this template clears the present trigger model.
Config List
Creates a trigger model that can recall settings that are stored in a
configuration list.
External Trigger
Creates a trigger model that allows you to use the digital I/O to
send signals to trigger external instruments. Settings that you can
change before generating the trigger model:
• Input line (default 1)
• Count (default 10)
• Delay (default 10)
• Output Line (default 2)
• Buffer (default defbuffer1)
Simple Loop
Creates a trigger model that sets up a loop that sets a delay,
makes a measurement, and then repeats the loop the number of
times you defined in the count parameter. Settings that you can
change before generating the trigger model:
• Count (default 50)
• Delay (default 0.001s)
• Buffer (default defbuffer1)
Duration loop
Creates a trigger model that sets up a loop that sets the amount of
time for which to take measurements (0 to 100,000 seconds), sets
a constant delay, makes measurements for the specified amount of
time (duration) and for the specified count, and saves the readings
to the specified buffer. Settings that you can change before
generating the trigger model:
• Duration (default 1.00s)
• Delay (default 0.001s)
Buffer (default defbuffer1)Creates a trigger model that sets up a
loop that sets the amount of time for which to take measurements
(0 to 100,000 seconds), sets a constant delay, makes
measurements for the specified amount of time (duration) and for
the specified count, and saves the readings to the specified buffer.
Settings that you can change before generating the trigger model:
• Duration (default 1.00s)
• Delay (default 0.001s)
•
Buffer (default defbuffer1)

Keithley 2450 Specifications

General

Model	2450
Category	SourceMeter
Voltage Source Range	±200 V
Current Source Range	±1 A
DC Voltage	200 V
DC Current	1 A
Power Output	20 W
Resolution	6.5 digits
Display	5-inch capacitive touchscreen
Operating Temperature	0°C to 50°C
Connectivity	USB, LAN, GPIB
Dimensions	213 mm × 88 mm × 370 mm
