Model 2450
Interactive SourceMeter® Instrument Reference Manual Appendix D:
Model 2450 in a Model 2400 application
2450-901-01 Rev. B/September 2013 D-29
Model 2400 command
:ARM[:SEQuence[1]][:LAYer[1]][:TCONfigure]:OLINe
:ARM[:SEQuence[1]][:LAYer[1]][:TCONfigure]:OLINe?
Model 2450 command
Not available
Notes
For similar functionality, use a digital I/O line with the trigger model.
Generate a notify event in the trigger model that feeds the stimulus setting to a
digital I/O line to pulse as needed in the trigger model.
See:
• :TRIGger:BLOCk:NOTify (on page 6-146)
•
:TRIGger:DIGital<n>:OUT:STIMulus (on page 6-153)
Model 2400 command
:ARM[:SEQuence[1]][:LAYer[1]][:TCONfigure]:OUTPut
:ARM[:SEQuence[1]][:LAYer[1]][:TCONfigure]:OUTPut?
Model 2450 command
Not available
Notes
Similar functionality available with :TRIGger:BLOCk:NOTify (on page 6-146) set
to a digital I/O line.
Model 2400 command
:ARM[:SEQuence[1]][:LAYer[1]]:TIMer
:ARM[:SEQuence[1]][:LAYer[1]]:TIMer?
Model 2450 command
Not available
Notes
Similar functionality available using :TRIGger:TIMer<n>:COUNt (on page 6-
167) and :TRIGger:BLOCk:WAIT (on page 6-148).
Model 2400 command
:INITiate[:IMMediate]
Model 2450 command
:INITiate[:IMMediate] (on page 6-124)
Notes
Model 2400 command
:TRIGger:CLEar
Model 2450 command
Not available
Notes
Model 2400 command
:TRIGger[:SEQuence[1]]:COUNt
:TRIGger[:SEQuence[1]]:COUNt?
Model 2450 command
Not available
Notes
Similar functionality availability using :TRIGger:BLOCk:BRANch:COUNter (on
page 6-128).
Model 2400 command
:TRIGger[:SEQuence[1]]:DELay
:TRIGger[:SEQuence[1]]:DELay?
Model 2450 command
Not available
Notes
Similar functionality availability using :TRIGger:BLOCk:DELay:CONStant (on
page 6-139).
Model 2400 command
:TRIGger[:SEQuence[1]]:SOURce
:TRIGger[:SEQuence[1]]:SOURce?
Model 2450 command
Not available
Notes
Model 2400 command
:TRIGger[:SEQuence[1]][:TCONfigure][:ASYNchronous]:INPut
:TRIGger[:SEQuence[1]][:TCONfigure][:ASYNchronous]:INPut?
Model 2450 command
Not available
Notes
