Appendix
D: Model 2450 in a Model 2400 application Model 2450 Interactive SourceMeter® Instrument Reference Man
ual
D-30 2450-901-01 Rev. B/September 2013
Model 2400 command
:TRIGger[:SEQuence[1]][:TCONfigure]:DIRection
:TRIGger[:SEQuence[1]][:TCONfigure]:DIRection?
Model 2450 command
Not available
Notes
Similar functionality available with :TRIGger:BLOCk:WAIT (on page 6-148).
Model 2400 command
:TRIGger[:SEQuence[1]][:TCONfigure]:ILINe
:TRIGger[:SEQuence[1]][:TCONfigure]:ILINe?
Model 2450 command
Not available
Notes
For similar functionality, use a digital I/O line with the trigger model.
Generate a notify event in the trigger model that feeds the stimulus setting to a
digital I/O line to pulse as needed in the trigger model.
See:
• :TRIGger:BLOCk:NOTify (on page 6-146)
•
:TRIGger:DIGital<n>:OUT:STIMulus (on page 6-153)
Model 2400 command
:TRIGger[:SEQuence[1]][:TCONfigure]:OLINe
:TRIGger[:SEQuence[1]][:TCONfigure]:OLINe?
Model 2450 command
Not available
Notes
For similar functionality, use a digital I/O line with the trigger model.
Generate a notify event in the trigger model that feeds the stimulus setting to a
digital I/O line to pulse as needed in the trigger model.
See:
• :TRIGger:BLOCk:NOTify (on page 6-146)
•
:TRIGger:DIGital<n>:OUT:STIMulus (on page 6-153)
Model 2400 command
:TRIGger[:SEQuence[1]][:TCONfigure]:OUTPut
:TRIGger[:SEQuence[1]][:TCONfigure]:OUTPut?
Model 2450 command
Not available
Notes
Similar functionality available with :TRIGger:BLOCk:NOTify (on page 6-146) set
to a digital I/O line.
Model 2400 command
:TRIGger:SEQuence2:SOURce
:TRIGger:SEQuence2:SOURce?
Model 2450 command
Not available
Notes
Model 2400 command
:TRIGger:SEQuence2:TOUT
:TRIGger:SEQuence2:TOUT?
Model 2450 command
Not available
Notes
