MIDI transmission when the M3’s controllers are operated Dynamic MIDI Destinations
609
(1):When a KARMA controller is assigned to a CC#
indicated by [*] (Global P2: Controllers– MIDI CC#
Assign)
*: Assignable
[*]:The X–Y, KARMA Controllers, and Pads controllers can
be assigned to CC#00–119. CC#s indicated by [*] will be
assigned automatically when you execute the Global P2–
MIDI CC# Assign menu command Reset Controller
MIDI Assign with the CC Default setting.
The CC Default settings are the CC#s recommended as
the CC# for each of these controllers. Normally you
should use these settings when assigning CC#s.
When one of the M3’s controllers is operated, the
corresponding or the assigned control change will be
transmitted.
If you choose KARMA Slider 1–8, KARMA Switch 1–8, or
PAD 1–8, its MIDI control change message will be
transmitted according to the settings in Global P2– MIDI
CC# Assign.
The following sections describes operation in each mode.
Program mode
When one of the M3’s controllers is operated, a control
change message will be transmitted on the global MIDI
channel (MIDI Channel Global 1–1a).
f the Realtime Control Slider 1–8 or the assignable
pedal has been set to Master Volume, the universal
system exclusive message Master Volume will be
transmitted.
Combination mode
When one of the M3’s controllers is operated, a control
change message will be transmitted on the global MIDI
channel (MIDI Channel Global 1–1a).
Simultaneously, the message will also be transmitted on the
MIDI channel (MIDI Channel Combi 3–1(2)c) of any timbre
whose Status (Combi 3–1(2)c) is EXT or EX2.
When one of the M3’s controllers is operated, its effect will
apply to any timbre whose Status is INT and whose MIDI
Channel setting is either Gch or the same as the global MIDI
channel.
In the case of Master Volume, the universal exclusive
message Master Volume will be transmitted only on the
global MIDI channel.
You can make settings for MIDI Filter (Combi P5) to
enable or disable control changes and controllers for
each timbre. When checked, the above operations will
be enabled.
Effect dynamic modulation can be controlled when the Ch
(Combi 8–1–4a, 9–2a) setting for IFX1–5, MFX1, 2, or TFX is
either set to Gch or to the same channel as the global MIDI
channel. (In the case of All Routed, control is possible on the
MIDI channel of any routed timbre.)
KARMA modules A, B, C, and D can be controlled if the In
(Input Channel) and Out (Output Channel) (Combi 7–1–
1c) settings specified for each module are Gch or match the
global channel.
Sequencer mode
When one of the M3’s controllers is operated, its effect will
apply to the MIDI track 1–16 that is selected by Track Select
(Seq 0–1–1(2)a).
If the Status (Seq 3–1(2)c) of the track selected by Track
Select is EXT, EX2, or BTH, a control change message will be
transmitted on the MIDI channel specified by MIDI
Channel (Seq 3–1(2)c).
If the Status is INT or BTH, operating one of the M3’s
controllers will affect only that MIDI track. Simultaneously,
the same effect will also apply to any MIDI track with the
same MIDI Channel setting.
In the case of Master Volume, the universal exclusive
message Master Volume will be transmitted.
You can make settings for MIDI Filter (Seq P3) to enable
or disable control changes and controllers for each
track. When checked, the operations effective for a
Status of INT or BTH will be enabled. Tracks whose
Status is EXT, EX2, or BTH will transmit control
changes regardless of this setting.
Effect dynamic modulation can be controlled when the Ch
(Seq 8–1–4a, 9–2a) setting for IFX1–5, MFX1, 2, or TFX
matches the MIDI channel of the track selected by Track
Select. (In the case of All Routed, control is possible on the
MIDI channel of all routed tracks.)
If one of the M3’s controllers is operated during realtime
recording, the corresponding or assigned control change
will be recorded.
KARMA modules A, B, C, and D can be controlled if the In
(Input Channel) and Out (Output Channel) (Seq 7–1–1c)
settings specified for each module are Tch or match the
MIDI channel of the MIDI track selected by Track Select.
Sampling mode
When one of the M3’s controllers is operated, a control
change message will be transmitted on the global MIDI
channel (MIDI Channel Global 1–1a).
In the case of Master Volume, the universal exclusive
message Master Volume will be transmitted.
It is not possible to make AMS settings in Sampling
mode.
Program change
Channel aftertouch **
Pitch Bend # (X) **
Universal exclusive
Master volume * *
Master balance
Master fine tune
Master coarse tune
KARMA
Available
for AMS
Available
for Dmod
MIDI messages
Joystick
Ribbon
X–Y
Mode
X–Y CC
Control
Value
Slider
Realtime
Slider
1…4
Realtime
Slider
5…8
SW1, 2 On/Off Latch Scene
SW
1…8
Slider
1…8
Pad
1…8
Damper
Foot
Switch
Foot
Pedal
