4-4 Service Manual
5061
323 M3.5x8 mm
Plastite Thread
Forming
(continued)
Left lower cover to lower frame Attach 2
Left upper cover asm to lower frame Attach 2
Left upper cover asm to upper frame Attach 1
Left lower pivot to lower frame Attach 2
Left upper pivot lower frame Attach 1
Rear cover to lower frame, left cover Attach 6
Rear fan cover to lower frame and top
cover
Attach 4
RIP fan assembly to upper frame Attach 1
Cartridge contact caps to housing Attach 8
Rear cover to lower frame, left cover and
top cover
Attach 10
Top cover asm to upper front cover Attach 3
Top cover asm to card shield Attach 1
ITU light shield asm to upper front guide
ITU
Attach 1
Ribs to upper redrive door Mounting 5
Upper door hinges to upper frame (redrive) Mounting 2
Inner redrive asm to upper frame (redrive) Mounting 2
Developer HVPS to cartridge contact asm Mounting 4
BOR drive asm to upper frame Mounting 1
ITU drive asm to lower frame Mounting 3
Fuser drive asm to lower frame Mounting 4
Vacuum top duct to lower frame Mounting 2
Toner shield to lower frame Attach 4
Diverter gate to lower frame (PF XPORT) Mounting 2
VTB asm to lower frame (PF XPORT) Mounting 3
Inner deflector to lower frame (PF XPORT) Attach 1
Jam access spring to VTB asm
(PF XPORT)
Attach 1
500 pick assembly to lower frame Mounting 3
Media size sensing assembly to lower
frame
Mounting 1
Paper level sensing assembly to lower
frame
Mounting 3
Duplex actuator bracket to lower frame Mounting 2
Fuser top duct to lower frame Mounting 1
Tray interlock bellcrank to lower frame Attach 1
Front left light shield to upper front cover
and front left handle assembly
Mounting 2
Card support plate to frame Mounting 2
Card shield to lower frame Mounting 3
Reference
number
Screw type Location Purpose Qty
