Lucent Technologies 5ESS - PH Equipage - Two Shelves

Table 4-4 PH equipage - one shelf (continued)
Number of PHs Horizontal EQL
6 062, 128, 030, 160, 046, 144
7 062, 128, 030, 160, 046, 144, 014
8 062, 128, 030, 160, 046, 144, 014, 176
When equipping more than one shelf, the pattern is slightly different.
Table 4-5, “PH equipage - two shelves” (4-8) provides a partial
pattern to follow when equipping two shelves. When additional PHs
are added, the same pattern is expanded as required.
Table 4-5 PH equipage - two shelves
PHs per
Shelf
First shelf Horizontal
EQL
Second shelf Horizontal
EQL
1 062 128
2 062, 128 128, 062
3 062, 128, 030 128, 062, 160
4 062, 128, 030, 160 128, 062, 160, 030
5 062, 128, 030, 160, 046 128, 062, 160, 030, 144
6 062, 128, 030, 160, 046,
144
128, 062, 160, 030, 144,
046
7 062, 128, 030, 160, 046,
144, 014
128, 062, 160, 030, 144,
046, 176
8 062, 128, 030, 160, 046,
144, 014, 176
128, 062, 160, 030, 144,
046, 176, 014
When additional shelves are added, the above pattern is extended as
required.
Packet Switch Unit Model 2 (PSU2)
Considerations
Engineering Considerations
....................................................................................................................................................................................................................................
4-8
