Delete an Existing SIP Call-Processing SM
....................................................................................................................................................................................................................................
Purpose
This procedure is used to delete a SIP call-processing SM.
When to use
Use this procedure to delete an existing SIP call-processing SM.
Related information
Refer to 235-118-258, Recent Change Reference for information on
the RC/V system.
Refer to the 235-600-700/750, Input/Output Messages manuals for
additional information on the Input and Output commands.
Admonishments
None.
Before you begin
Required Tools
• Supplemental Trunk Line Workstation (STLWS) or Recent
Change and Verify (RC/V) terminal
• Access to RC/V Menu Interface
Required Material
• The 5ESS
®
switch must be running a 5E16.2 FR3 software
release or later with the SIP for Packet Trunking - NAR feature
software.
Required Information
• Call Processing SM number and SIP GSM number
Required Conditions
• None
Procedure
............................................................................................................................................................
1
Select and prepare terminal for RC/V activities.
Reference:
“Select and Prepare Terminal” (5-11)
............................................................................................................................................................
2
On RC/V 5.81, update the ROUTE field for the desired SIP CP SMs
to N, so that new calls will not be routed to those SMs.
Deprovisioning
....................................................................................................................................................................................................................................
6-92
Lucent Technologies 235-200-118
Issue 3.02B, March 2007
