Define Protocol Handler (RC/V 22.4)

....................................................................................................................................................................................................................................

Purpose

The Equipment Subunit Protocol Handler view (22.4) defines the

hardware for the protocol handlers equipped on the shelf.

When to use

Use this procedure to define PH if a PH does not exist in the switch.

Related information

Refer to 235-118-258, Recent Change Reference, for information on

the RC/V system.

Refer to 235-105-231, Hardware Change Procedures - Growth for

information on PH growth.

Admonishments

None.

Before you begin

Required Tools

• Supplemental Trunk Line Workstation (STLWS) or Recent

Change and Verify (RC/V) terminal

• Access to RC/V Menu Interface

Required Material

• The 5ESS

switch must be running a 5E16.2 FR3 software

release with the SIP for Packet Trunking - NAR feature software.

• The PHs must be installed in the shelf of the PSU2.

Required Information

• Switching Module (SM) Number

• Packet Switching Interface Unit Number

• Packet Switching Unit Shelf Number

• Position

Required Conditions

• The CRIT PSU (critical PSU2) must be set to N on RC/V 22.2.

Procedure

............................................................................................................................................................

Refer to the growth procedures documentation.

Reference:

235-105-231, Hardware Change Procedures - Growth

Provisioning

5-18

Lucent Technologies 235-200-118

Issue 3.02B, March 2007

E ND OF S TEPS
