Table 2-3 GQPH Characteristics (continued)
Software Image PH33Q
Hardware Type PH33
Pack Code TN113
Note: The GQPHs are only on the non-DRM/VCDX.
Refer to Hardware Description, 235-100-200 for additional
information on the PH33.
Pack physical
characteristics
Each SIP PH or GQPH circuit pack is located in a PH slot as
required. They each contain two amber LEDs in the faceplate. Refer
to Figure 2-14, “Pack Faceplates” (2-26) for an example of the SIP
PH and GQPH faceplates and LEDs. Both the out-of-service (OOS)
and signal fail (SF) LEDs are illuminated when the packs are removed
from service. The SF LED, on the SIP PH only, is also illuminated
when there is no signal from the Ethernet termination.
The LLE2 paddle board is located on the back side of the PSU2. One
paddle board is attached to the upper pin field directly behind the
corresponding SIP PH. The paddle board is equipped with an SF
LED. The SF LED is illuminated when there is no signal from the
Hardware View
Architecture
....................................................................................................................................................................................................................................
235-200-118
Issue 3.02B, March 2007
Lucent Technologies
2-25
