Í Structure of reference input, page 24
82x-RNA0, 83xRNA1 - Scaling for analog reference input 0 or 1
Source: Reference Norm Analog Input 0, 1
Function: Scaling for analog reference input 0 or 1
Í Structure of reference input, page 24
431-ROPT1, 432-ROPT2 - Reference value of option slot 1 or 2
Source: Reference from Option 1, 2
Function: Module in slot 1, 2
These parameters display the reference value of modules in slot 1 or 2
(option slot 2 is only on the MC6000).
The modules can be selected as reference sources.
Í Structure of reference input, page 24
429-RPOT - Reference value of MOP
Source: Reference Potentiometer
Function: MOP function via digital inputs
This parameter only displays the MOP reference value.
Í Structure of reference input, page 24
Note:
If RLIM1 > RLIM2 is set, error E-PAR is signaled
(parameter list invalid).
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
-32764 32764 50
10
3000
100
Hz
Nm
rpm
–
R1W2 REFRC INT32Q16
Example,
speed
control:
RNA0 = 3000 means that a reference value of +10 V corresponds to a reference
speed of 3000 rpm.
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
-32764 32764 0 – R4W15 ALL INT32Q16
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
-32764 32764 0 – R4W15 ALL INT32Q16
