_CONF – Device configuration and I/O Subject area • 35Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
296-OPTN1 - Assignment of slot 1
Source: Option1
Function: Identifier of module in option slot 1
OPTN1 on MC6000
OPTN1 on MC7000
293-OPTN2 - Assignment of slot 2
Source: Option 2
Function: Identifier of module in option slot 2
OPTN2 on MC6000
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
See table NONE – R5W15 ALL USIGN8
Settings:
Bit position Value of position Meaning of bit
0 0001 H CAN bus
16 01FF H InterBus-S
Settings:
Bit position Value of position Meaning of bit
0 0001 H Analog output 4-channel
1 0002 H Analog output 2-channel
2 0004 H Analog output 1-channel
3 0008 H CANopen
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
See table NONE – R5W15 ALL USIGN8
Settings:
Bit position Value of position Meaning of bit
0 0001 H I/O expansion
1 0002 H Analog output 4-channel
2 0004 H Analog output 1-channel
16 01FF H P
OSMOD
