_CONF – Device configuration and I/O Subject area • 29Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
Í Example of use of output OS00:, Page 34
445-FOS00 - Function selector, output OS00
Source: Function Selector Output Standard 00
Function: Function selector for output OS00; determines which variable is delivered at the output.
Examples:
l REF - Reference (e.g. speed) reached
l ERR - Error message
Í Functions for outputs on MC6000
, Page 30
Í Functions for outputs on MC7000, Page 32
446-FOS01- Function selector, output OS01
Source: Function Selector Output Standard 01
Function: Function selector for output OS01; determines which variable is delivered at the output.
Examples:
l REF - Reference (e.g. speed) reached
l ERR - Error message
Í Functions for outputs on MC6000
, Page 30
Í Functions for outputs on MC7000, Page 32
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
TORQE IA1 SPEED – R1W2 REFRC USIGN8
Setting Output variable
TORQE Current torque
SPEED Current speed
POS Current position
CURNT Current effective output current
IA0 Input difference at input ISA0
IA1 Input value at input ISA1
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
OFF TCAVM /ERRW – R1W2 REFRC USIGN8
Note:
Output OS00 can also be used as a PWM output (quasi-analog);
see parameter FOA0.
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
OFF TCAVM ACTIV – R1W2 REFRC USIGN8
