28 • _CONF – Device configuration and I/O Subject area Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
Example: Parameter data of group 1 are to be backed-up in the FLASH.
Set 1st parameter FLAGP to 1.
Set 2nd parameter FLABU to 1, i.e. BUSY.
133-FLALL - Store all FLASH parameters
Source: Flashbackup all groups
Function: Parameter only on MC7000.
All parameters of type “FLASHEPROM” are backed-up to the Flash EPROM.
449-FOA0 - Function selector for analog function of output OS00
Source: Function Selector Output Analog 0
Function: Function selector determining which variable is delivered at output OS00 pulse width modu-
lated or analog.
The output then delivers a quasi-analog output signal suitable for time-lag display instru-
ments but not for processing in controllers!
The output signal is scaled by OA0MN and OA0MX (_CONF).
Attention!
Not the complete FLASH EPROM is saved, only a group. The user must therefore
known the group number of the parameters.
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
See table READY – R5W5 Non USIGN8
Settings:
No. Setting Function
0READY
Backup is complete and can be restarted
(value to BUSY)
1 BUSY Backup started
Note:
The data backup may take a few seconds, as all the groups have to be backed-up in
succession.
Attention!
During data backup the device must not be switched off!
