98 • _REF – Reference structure Subject area Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
434-REF1 ... 438-REF6 - Interim values of reference input
Source: Reference Value 1 - 6
Function: Interim values of reference input
These parameters display the reference value (interim stages) on the reference channels.
They are useful for troubleshooting in reference input.
Í Structure of reference input, page 24
448-RF3FA - Factor for reference channel 3
Source: Reference Channel 3 Factor
Function: Factor for percentage scaling of the reference value on channel 3
Í Structure of reference input, page 24
74x-RFIX1 ... 79x-RFIX6 - Fixed references 1 to 6
Source: Reference Fixed Value 1 - 6
Function: Fixed references 1 to 6; the programmed values can be selected and switched with a refer-
ence selector RSSLx.
Examples of parameter numbers:
740-RFIX1 – Fixed frequency 1
741-RFIX1 – Fixed torque 1
742-RFIX1 – Fixed speed 1
743-RFIX1 – Fixed position 1
Í Structure of reference input, page 24
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
-32764 32764 0 – R4W15 ALL INT32Q16
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0 100 100 % R4W4 REFRC USIGN16
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
-32764 32764 0 Hz, Nm,
rpm
R1W2 REFRC INT32Q16
