_SYS – Diagnosis and digital scope Subject area • 93Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
36-DSVTC - Index of trigger channel for values table of Trace tool
Source: Digital Scope Value Trigger Channel
Function: Variable for the trigger channel
Í Digital scope, page 88
19-EEPCC - Number of repairs to EEPROM
Source:
Function: The number of repairs should actually be = 0. If the number is >100, error E-EEP is trig-
gered with error location 12.
CAUTION - Do not change parameter!
Parameter only for development and service purposes
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0000H FFFFH 0000H – R5W5 ALL USIGN16
The exact use of this parameter is dependent on the values of parameters DSTM and
DSTCH:
DSTM DSTCH => DSVTC
1...4 0...3 Not used
1...4 4 Indicates the index of the 16-bit trigger variable
1...4 5 Indicates the index of the 32-bit trigger variable
5...7 x
Contains the address of a bit from the"bitFeld[ ]" field
such that the High byte designates the field index and
the Low byte the index of the bit in this word. The de-
finition is "flagword bitFeld[SIZE_OF_BITFELD]";
The precise significance of the bits must be obtained
from a table which still remains to be created.
8...9 x
In the High byte contains the error number and in the
Low byte the error location of the warning or error in
response to which the trigger is to occur.
CAUTION - Do not change parameter!
Parameter only for development and service purposes
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0 65535 0 – R5W6 ALL USIGN16
