70 • _PCON – Position control Subject area Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
113-PCRMD - Max. number of revolutions in referencing
Source: Position Control Referencedrive Maximum Distance
Function: Indication of the maximum number of revolutions for a reference run without the reference
cam having been activated. When this threshold value is exceeded output OSxx “Referen-
cing error“ is set, if the output has been assigned the REERR or REFOK (= Reference run
successful) function with the function selector FOSxx.
For stepper motor interface and electronic gearing modes.
112-PCRV - Referencing speed
Source: Position Control Reference Velocity
Function: Maximum positioning speed during referencing. The positioning speed must be in the
range - SCSMX ... + SCSMX (parameter no. 384).
For stepper motor interface and electronic gearing modes.
380-PCTS - Sampling time of position controller
Source: Position Controller Time Sampling
Function: Sampling time of the position controller (250 µs or 500 µs on MC7000 with 4 kHz switching
frequency PMFS).
117-PCZS - Offset machine zero relative to reference point
Source: Position Control Zeropoint Offset
Function: Distance between reference point and machine zero.
The machine zero is shifted by this value (zero correction).
For stepper motor interface and electronic gearing modes.
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
100 32000 32000 rev R2W2 APPLI USIGN16
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
-3000 3000 100 rpm R2W2 APPLI INT16
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0.00025 0.0005 0.00025 s R4W15 DRIVE FLOAT32
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
-32000 32000 0
Incre-
ments
R2W2 APPLI INT32Q16
Note:
The parameter only takes effect when automatic zeroing is activated. (PCAZ = ON).
