62-DSMSZ - Size of transient memory in bytes
Source: Digital Scope Memory Size
Function: Size of transient memory
Maximum value on MC6000: Factory setting, on MC7000 dependent on memory capacity
and operation mode (not available for PosMod, for example).
Í Digital scope, page 88
67-DSPRT - Pretrigger of digital oscilloscope
Source: Digital Scope Pretrigger
Function: Pretrigger of digital oscilloscope
The parameter is scaled to 0.05. The setting range is real 0-100 % in stepwidths of 0.05%.
Í Digital scope, page 88
Bit position Hex value Meaning
0.. 4 0..1Fh Left-shift value for the recorded variable. For 32-bit
variables the value should be less than 32, and for
16-bit variables less than 16. This functionality only
makes sense for DA output. For the digital scope
this value is always 0.
5 20h Channel on/off
640h
0 -> Value from 16-bit table, 1 -> Value from 32-bit
table
7 80h Not used
CAUTION - Do not change parameter!
Parameter only for development and service purposes
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
061446144– R5W5 ALL USIGN16
CAUTION - Do not change parameter!
Parameter only for development and service purposes
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0.00 100.00 10.00 % R5W5 ALL FIXPOINT16
