_CONF – Device configuration and I/O
412-ANFIL – Filter time constant for analog inputs
Source: Analog Filter Constant
Function: Time constant of the analog filter of the analog reference inputs ISA0, ISA1
7-AUTO – Activate/deactivate Auto-Start
Source: Auto-Start TEST
Function: When Auto-Start is active control is immediately active after power-up, provided a Start
command is received at the terminals.
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
See table 0 – R4W4 REFRC USIGN8
Settings:
ANFIL on MC6000 ANFIL on MC7000
Setting Function Setting Function
00 ms 00 ms
1 1 ms 1 0.1 ms
2 2 ms 2 0.2 ms
3 4 ms 3 0.5 ms
48 ms 41 ms
5 16 ms 5 2 ms
64 ms
Note:
For fault isolation increase time constant. Use if reference value is corrupted by
disturbances on the analog signal.
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
OFF ON OFF – R1W2 SYSTM USIGN8
Settings:
No. Setting Function (Control starts ... )
0OFF
positive edge triggered, e.g. input IS00
FIS00 = START (factory setting)
1ON
status-controlled, e.g. FIF0 = START can be programmed,
then input IS00 is free for other function
Note:
No other input is required if one of the fixed inputs FIF0 or FIF1 = START is
programmed.
