490-CASTA – CAN bus status word
Source: CAN-Bus Status Word
Function: Current status word
DriveCOM status word (not where CACNF = 4):
11 vacant
12 vacant
13 vacant
14 Reference state output OS00 1), S1OUT 2)
15 Reference state output OS01 1), S2OUT 2)
1) MCxxxx, 2) VF1xxx
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0000H FFFFH 0000H – R3W15 ALL USIGN16
In the status word the current state of the device and additional messages are dis-
played. The following bits of the DRIVECOM STATUS WORD are supported:
Bit Name
0 Ready for start
1On
2 Operation enabled
3 Error
4 Power disabled
5 Emergency stop
6 Switch-on inhibit
7 Warning
8 No function
9 Remote
10 Reference reached
11 Limit value
12, 13 Mode-dependent, more detailed definition:
DRIVECOM profile no. 22 of January 1994
14 Actual state input IS00 1), S1IND 2)
15 Actual state input IS01 1), S2IND 2)
1) MCxxxx, 2) VF1xxx
Bit Name (continued)
