104 • _REF – Reference structure Subject area Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
Í 126-RSDIR - Level of directional signal for stepper motor mode, page 102
Í 390-RDDEN - Transmission ratio of rotation speed (denominator), page 97
Í 389-RDNOM - Transmission ratio of rotation speed (numerator), page 97
421-SADD1 ... 424-SADD4 - Offset for reference selector 1 ...4
Source: Selector Addition Value for RSSL1 - 4
Function: Offset for reference selectors 1 to 4 (RSSL1 - RSSL4), to switch
reference sources during operation.
The offset is set via digital inputs. The parameters SADDx only display the current offset
value (switchover distance).
Í Structure of reference input, page 24
496-STOPR - Stop ramp
Source: Stop Ramp
Function: Stop ramp (for quick-stop\
)
The parameter determines the ramp, in the unit rpm per s, with which the motor is braked to
speed = 0. In the setting STOPR = 0 (factory setting) the motor is braked as quickly as pos-
sible at the preset torque limit TCMMX\ (quick-stop without ramp).
Quick-stop (/STOP)
The quick-stop function can be used as a safety function. The quick-stop can be triggered from various
control locations:
By way of the stop ramp parameter STOPR (_CONF) the ramp with which the motor is braked down to
speed = 0 can be specified, in the unit rpm per s. In the setting STOPR = 0 (factory setting) the motor is
braked as quickly as possible at the preset torque limit (TCMMX in subject area _TCON) (quick-stop
without ramp).
The drive control remains active, and the motor is held in this position under speed control. The quick-
stop can be activated in any control mode.
Settings:
No. Setting Function
0OFF
Stepper motor interface is shut off
(A-B signals)
1ON
Stepper motor interface is on
(pulse direction signals)
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0150 – R4W15 ALL USIGN8
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0 65535 0 rpm/s R1W2 REFRC USIGN16
