90 • Subject area _SYS – Diagnosis and digital scope Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
68-DSRUN - Start enable of digital oscilloscope
Source: Digital Scope Run
Function: Start enable of digital oscilloscope
In the write operation to this parameter only bit 0 is influenced. In read operations bit 0 and
bit 1 are read.
Í Digital scope, page 88
66-DSTCH - Trigger channel of digital oscilloscope
Source: Digital Scope Trigger-Channel
Function: Trigger channel of digital oscilloscope
Í Digital scope, page 88
CAUTION - Do not change parameter!
Parameter only for development and service purposes
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
070 – R5W5 ALL USIGN8
Value Meaning
0 Digital scope is off, data recording
finished
2 Digital scope has triggered, data
recording is active
5 Digital scope is active and waiting for
trigger signal
CAUTION - Do not change parameter!
Parameter only for development and service purposes
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0 5 0 – R5W5 ALL USIGN8
Value Meaning
0 Trigger channel 0
1 Trigger channel 1
2 Trigger channel 2
3 Trigger channel 3
