116 • Subject area _PMOD – Open-loop position control (option) Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
545-POAPO - Current program set number of active positioning program
544-POAPR - Number of active positioning program
555-POASP - Current reference position in distance units
Function: Parameter only on MC7000.
The parameter indicates the number of the program set of the current positioning
program which is to be executed when the still running positioning set is finished.
Í 544-POAPR - Number of active positioning program, page 116
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0 65535 0 – R1W3 – USIGN16
Function: Parameter only on MC7000.
The parameter indicates the number of the positioning program currently being
worked through in the position controller, e.g. in program P01 Í display: "1".
This information is displayed in the Active device – Monitor – Positioning module
MC7000 menu.
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0990 – R1W3 – USIGN8
Note:
The program to start is defined on the Inputs tab (program selection).
Function: Parameter only on MC7000.
Indicates the current reference position of the position control in distance units.
Í 554-POAIP - Current actual position in distance units, page 115
Í Distance unit, page 114
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
-32764 32764 0 – R1W7 – INT32Q16
