106 • Subject area _IO1 – Inputs Parameter Description MC6000/7000

_ENCD

_VAL

Index

_VFCON

_PMOD

_KPAD

Contents

Introduction

_SIO

_SCTY

_REF

_SYS

_IO1

_IO2

_CAN

_OPT1

_MOT

_CONF

_TCON

_SCON

_PCON

_IO1 – Inputs

455-FIE00 ... 462-FIE07 - Function selector, external inputs IE00 ... IE07

Source: Function Selector Input External 0 - 7

Function: Function selectors for external inputs 0 to 7 (I/O module)

Examples: l AD3-0 – To switch between various references, for example, various preprogrammed

reference values can be selected (AD3-0 switches to the next Reference source of the

3rd reference channel)

l AD3-1 – To switch between various references, for example, various preprogrammed

reference values can be selected (AD3-1 switches by two Reference source of the 3rd

reference channel)

Í Functions for inputs on MC6000, page 21

Í Functions for inputs on MC7000, page 22

Í Structure of reference input, page 24

Í Notes on function selectors for inputs, page 23

479-SIEXT - Status word of external inputs IE00...IE07

Source: Status Word Input Extern

Function: Status word of the external inputs (I/O module) to scan the inputs via serial interface

Values:

Minimum Maximum Factory set. Unit MODE SMARTCARD Type

OFF EGEAR OFF – R4W4 REFRC USIGN8

Values:

Minimum Maximum Factory set. Unit MODE SMARTCARD Type

0000H FFFFH 0000H – R4W15 ALL USIGN16

Bit Hex value Function

0 0001 H Scan input IE00

1 0002 H Scan input IE01

2 0004 H Scan input IE02

3 0008 H Scan input IE03

4 0010 H Scan input IE04

5 0020 H Scan input IE05

6 0040 H Scan input IE06

7 0080 H Scan input IE07
