74 • Subject area _SIO – Serial interface RS485 Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
_SIO – Serial interface RS485
82-SADDR - LustBus device address
Source: Serial Address
Function: Serial address of the device
81-SBAUD - LustBus transfer rate
Source: Serial Baud Rate
Function: Baud rate of the serial interface (data transfer rate)
416-SCTL1 - Control word of serial interface
Source: Serial Control Word 1
Function: Control word 1 of the serial interface
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0301 – R4W4 ALL USIGN8
Special
Addresses:
l The address 0 addresses every servocontroller in non-network operation.
l The address 31 addresses all networked devices ("Broadcast"); without checkback.
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
9600 57600 19200 1/s R4W4 SYSTM USIGN8
No. Function
0 9600 Bit/s
1 4800 Bit/s
2 2400 Bit/s
3 1200 Bit/s
4 19200 Bit/s
5 28800 Bit/s
6 57600 Bit/s
Note:
A changed baud rate is not activated immediately. Only when the device is switched
back on is the serial interface set to the changed transfer rate.
A change in baud rate in operation can be made by means of parameter PROG
= 111 in subject area _KPAD.
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0 65535 0 – R4W4 ALL USIGN16
