Lust MASTERCONTROL MC6000 Series User Manual

34 • _CONF – Device configuration and I/O Subject area Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
Í MOP function, Page 99
Í Parameter setting for the MOP function, Page 99
Í Operation modes of the MOP function, Page 100
481-OA0MN - Lower window limit for analog output OS00
Source: Output Analog 0 Minimum Value;
Function: For the PWM function of output OS00:
OA0MN= minimum output value (value of output variable at 0V)
The parameters are also used on MC6000 servocontrollers with D/A output module,
version AH4.
482-OA0MX - Upper window limit for analog output OS00
Source: Output Analog 0 Maximum Value
Function: For the PWM function of output OS00:
OA0MX= Maximum output value (value of output variable at 24V)
Example of use of output OS00:
With factory setting:
• Function selector FOA0\ (= SPEED)
• Lower limit OA0MN (= 0)
• Upper limit OA0MX (= 3000)
and selection of the PWM function by FOS00=ANALG (_CONF) the current speed is delivered via
OS00.
The parameters OA0MN and OA0MX determine the speed window: 0 ... 3000 rpm then correspond
to 0 ... +24 V.
Setting Function
0 Status-controlled, without reset
1 Status-controlled, with reset
2 Edge-controlled, without reset
3 Edge-controlled, with reset
Operation with reset means the reference value of the MOP is set = 0.
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
-32764 32764 0 – R4W4 REFRC INT32Q16
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
-32764 32764 3000 – R4W4 REFRC INT32Q16
