30 • _CONF – Device configuration and I/O Subject area Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
463-FOS02- Function selector, relay output OS02
Source: Function Selector Output Standard 02
Function: Parameter only on MC7000.
Function selector for output OS02; determines which variable is delivered at the output.
Examples:
l REF - Reference (e.g. speed) reached
l ERR - Error message
Í Functions for outputs on MC6000
, Page 30
Í Functions for outputs on MC7000, Page 32
464-FOS03- Function selector, brake output OS03
Source: Function Selector Output Standard 03
Function: Parameter only on MC7000.
Function selector for output OS03; determines which variable is delivered at the output.
Examples: l BRAKE - Activation of motor holding brake, further setting with
parameter BRAKE
l REF - Reference (e.g. speed) reached
l ERR - Error message
Í Functions for outputs on MC6000
Í Functions for outputs on MC7000
Functions for outputs on MC6000
Outputs: OS00: Standard output, digital or PWM (analog)
OS01: Standard output, digital
OExx: External outputs (I/O module)
Factory setting
l Output can execute this function
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
OFF TCAVM OFF R1W2 REFRC USIGN8
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
OFF TCAVM OFF R1W2 REFRC USIGN8
