_CONF – Device configuration and I/O Subject area 31Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
No. Setting Function:
OS00
OS01
OExx
0OFF None
ll
1ERR Error
lll
2 WARN Warning
lll
3 /ERR No error
lll
4 /WARN No warning
lll
5 ACTIV Control in operation (green LED flashing)
l
l
6 ROT_R Rotate Right 1)
lll
7 ROT_L Rotate Left 1)
lll
8 ROT_0 No Rotation (energized) 1)
lll
9 LIMIT Limit value reached, dependent on parameter RLIM1,
RLIM2 (_REF)
lll
10 REF Reference reached, dependent on parameter REF_R
(_CONF)
lll
11 ASM Asynchronous machine parameterized
ll
12 SIO Output is assigned to serial interface
and can be set via SCTL1 (_SIO)
lll
13 OPTN1 Output is assigned to module in slot 1
and assigned function 2)
lll
14 OPTN2 Output is assigned to module in slot 2
and assigned function 2)
lll
15 ERRW Warning or error
lll
16 /ERRW No warning and no error
lll
17
18
19
20
USER0
USER1
USER2
USER3
Output can be used by modified software
(see relevant documentation),
with standard software no function
lll
lll
lll
lll
21 ANALG Output delivers analog (PWM) output signal, 3)
function is assigned by FOA0 (only FOS00)
lll
1) Dependent on parameter SPD_0 (_CONF).
2) No function if module not fitted.
3) PWM signal 24 V, 200 Hz, e.g. for time-lag pointer instruments; smooth with RC element as
necessary.
Note:
The output delivers High level if the condition is met.
