54 • Subject area _MOT – Motor parameters Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
320-MONPP - Number of pole pairs of motor
Source: Motor Number of Pole Pairs
Function: Number of pole pairs of motor
314-MOR_R - Rotor resistance
Source: Motor Resistance Rotor
Function: Rotor resistance of the motor
313-MOR_S - Stator resistance
Source: Motor Resistance Stator
Function: Stator resistance of the motor
316-MOSMX - Maximum speed
Source: Motor Speed Maximum
Function: Maximum motor speed (only for asynchronous machines in the field weakening range)
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
143 – R4W5 DRIVE USIGN8
Note:
For resolvers, the number of pole pairs of the resolver (ECNPP) must be equal to
that of the motor or equal to one or a whole-number multiple of the number of pole
pairs of the motor.
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0.001 25 1.47 Ohm R4W5 DRIVE FLOAT32
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0.001 100 1.875 Ohm R4W5 DRIVE FLOAT32
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
50 12000 3000 rpm R1W5 DRIVE USIGN16
Note:
l On synchronous machines the nominal speed of the motor (MOSNM) corre-
sponds to the maximum motor speed.
l To limit the maximum speed in an application, use parameter SCSMX.
SCSMX must then be less than or equal to MOSMX.
