_SYS – Diagnosis and digital scope Subject area • 91Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
60-DSTIM - Time division of digital oscilloscope
Source: Digital Scope Time
Function: Time division of the digital oscilloscope in multiples of 62.4 µs (MC7000) or 124.8 µs
(MC6000) respectively
65535 = 2097.1 s
Í Digital scope, page 88
29-DSTF - Filter time constant of digital scope (only MC6000)
Source: Digital Scope Time Filter
Function: Filter time constant of the digital scope (only MC6000)
Í Digital scope, page 88
64-DSTLV - Trigger threshold of digital oscilloscope
Source: Digital Scope Trigger-Level
Function: Trigger threshold of digital oscilloscope
The parameter receives the scaled value of the trigger level. For 32-bit variables this value
corresponds to the upper 16 bits; the lower bits are always set to 0 in the M
ASTERCONTROL.
Í Digital scope, page 88
CAUTION - Do not change parameter!
Parameter only for development and service purposes
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0 65535 1 – R5W5 ALL USIGN16
CAUTION - Do not change parameter!
Parameter only for development and service purposes
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0 15 0 – R5W5 ALL USIGN8
CAUTION - Do not change parameter!
Parameter only for development and service purposes
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
-32768 32767 30 – R5W5 ALL INT16
