46 • _OPT1 – Slot 1 Subject area Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
_OPT1 – Slot 1
452-DA0MN, 454-DA1MN - Lower limit value of value range for channel 0
or 1 of analog output (AH7)
Source: Digital/Analog Minimum Value for Channel 0, 1
Function: Parameter for MC7000 with 2-channel analog output (AH7).
Minimum output value for channel 0 or 1 (value of output variable at - 10 V).
Í Application example for analog output AH7, page 47
453-DA0MX, 466-DA1MX - Upper limit value of value range for channel 0 or 1 of
analog output (AH7)
Source: Digital/Analog Maximum Value for Channel 0, 1
Function: Parameter for MC7000 with 2-channel analog output (AH7)
Maximum output value for channel 0 or 1 (value of output variable at + 10 V).
Í Application example for analog output AH7, page 47
450-FODA0, 451-FODA1 - Function selector for DA module for channel 0 or 1
Source: Function Selector Output Digital/Analog Channel 0, 1
Function: Parameter for MC7000 with 2-channel analog output (AH7).
Function selector determining which variable is delivered in analog form on channel 0 or 1.
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
-32764 32764 -3000 – R3W3 OPTN1 INT32Q16
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
-32764 32764 3000 – R3W3 OPTN1 INT32Q16
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
TORQE REFV SPEED – R3W3 OPTN1 USIGN8
No. Setting Function
0 TORQE Actual torque
1 SPEED Actual speed
2 POS Actual position
3 CURNT Effective phase current
4 IA0 Input difference at input ISA0
5 IA1 Input value at input ISA1
6 ASPED Amount of actual speed
7 REFV Reference
