Application example for analog output AH7
Parameter FODA0 = SPEED, DA0MN = - 3000 and DA0MX = + 3000: Then - 10 V correspond to a
speed of - 3000 rpm and + 10 V a speed of + 3000 rpm.
Speed: Output voltage:
Recommendations for setting of the AH7 parameters
Example: DA0MN = - 1000, DA0MX = + 3000.
Then both at 3000 rpm and at -1000 rpm an output voltage of + 10 V would be produced!
This does not make sense.
406-IBCNF - Configuration of reference transfer via InterBus-S
Source: InterBus-S Configuration
Function: Parameter only on MC6000.
The first word in the process data channel contains the control or status word according to
DRIVECOM profile 20. The remaining words in the process data channel are reserved for
reference transfer and actual value checkback. The interpretation of the reference and
actual value words can be set with parameter IBCNF.
Note:
The window limits do not need to be selected symmetrical to zero, nor do they need
to cover the entire possible input range (zoom). However, it should be taken into
account that with asymmetrical window limits an output voltage of 0 V does not corre-
spond to an input value of zero and values outside the window limits are limited to -
10 V and + 10 V respectively.
FODAx = DAxMN = DAxMX = Explanation
IA0 -2048 2047
IA1 0 2047
ASPED e.g. - 3000 e.g. + 3000
Symmetrical to zero, other-
wise see example
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
052 – R3W3 OPTN1 USIGN8
- 3000
+ 3000
- 10
+ 10
rpm
V
...
...
