_REF – Reference structure Subject area • 97Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
497-RCAN - Reference from CAN bus
Source: Reference from CAN-Bus
Function: Reference values via CAN bus
This parameter only displays the reference value from the CAN bus.
Í Structure of reference input, page 24
390-RDDEN - Transmission ratio of rotation speed (denominator)
Source: Reference Drive Denominator
Function: Denominator of the transmission ratio for speed synchronism (operation mode speed con-
trol via pulse input).
389-RDNOM - Transmission ratio of rotation speed (numerator)
Source: Reference Drive Nominator
Function: Numerator of transmission ratio for speed synchronism (operation mode speed control via
pulse input).
Í 126-RSDIR - Level of directional signal for stepper motor mode, page 102
430-RDIG - Digital reference input
Source: Reference from Digital Input
Function: Digital reference input
This parameter displays the reference value from the digital reference input
(e.g. speed reference in reference input via pulse input = speed synchronism).
Í Structure of reference input, page 24
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
-32764 32764 0 R4W15 ALL INT32Q16
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
1 65535 1 R1W2 APP USIGN16
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
1 65535 1 R1W2 APP USIGN16
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
-32764 32764 0 R4W15 ALL INT32Q16
