14 • _CONF – Device configuration and I/O Subject area Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
409-BUTWD - Bus watchdog time in ms
Source: Bus Time Watchdog
Function: Parameter only for CAN bus.
To monitor the bus activity (CAN bus or InterBus-S) a watchdog is provided.
With the parameter BUTWD the monitoring time in ms can be set. The value 0 deactivates
the watchdog.
304-CFCMX - Effective value of maximum current
Source: Configuration Current Maximum
Function: Maximum permissible effective value of the current (double overload for 10s). The value is
dependent on the device type, and is calculated automatically from the power stage identi-
fier.
Settings: CFCMX on MC6000 CFCMX on MC7000
303-CFCNM - Scaling current
Source: Configuration Current Nominal
Function: Device current dependent configuration parameter required for internal calculations and
derived automatically from the power stage identifier
.
Example: In MC6408 CFCNM = 25.76 A
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
02550 –R3W3SYSTMUSIGN8
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
Dependent on device type, see table A R4W7 ALL FLOAT32
Setting Device type Setting Device type
8A MC6404 4 A MC7402
16 A MC6408 8 A MC7404
24 A MC6412 16 A MC7408
32 A MC6416 24 A MC7412
64A MC6432 32 A MC7416
96A MC6464 64A MC7432
96A MC7464
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
Dependent on device type A R5W7 ALL FLOAT32
