_KPAD – KeyPad KP100
3-BARG - Parameter for bar graph display of KP100
Source: Bargraph (Displayed Parameter)
Function: Continuous actual value of bar graph display of KeyPad (defines which parameter is on per-
manent display on the bar graph display)
11-CASEL - Functional areas of SMARTCARD
Source:
Function: Divides into SMARTCARD
AREA. Not a user parameter, used only for SMARTCARD
OPERATIONS.
5-CTLFA - Multiplier for incremental value in CTRL menu of KP100
Source: CTRL-Menu Factor
Function: Factor to scale the MOP function\ of the CTRL menu on the KeyPad.
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
199977 – R4W4 SYSTM USIGN16
No. Setting Function
9 TAX Current controller workload
12 MIDTX Mean controller workload
10 MAXTX Maximum controller workload
427 TEMP Device temperature
77 SPEED Speed
76 TORQUE Torque
75 CURNT Effective output current
347 DCV DC-link voltage
495 IOSTA Status of inputs and outputs 1)
1) For description see parameter IOSTA in subject area _VAL.
CAUTION - Do not change parameter!
Parameter only for development and service purposes
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
ALL POMOD ALL – R6W& ALL USIGN8
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
1 65535 10000 – R4W4 SYSTM USIGN16
