104-PSW6 - Password for user level 6 of KP100

Source:

Function: Password Mode 6

Password for user level 6

(scan --PWx-- on change of user level MODE)

105-PSWCT - Password for Control menu of KP100.

Source: Password CTRL-Menu

Function: Password for CTRL menu (scan PASSW)

CAUTION - Do not change parameter!

Parameter only for development and service purposes

Values:

Minimum Maximum Factory set. Unit MODE SMARTCARD Type

0 65535 768 – R6W6 SYSTM USIGN16

Values:

Minimum Maximum Factory set. Unit MODE SMARTCARD Type

0 65535 0 – R3W3 SYSTM USIGN16
