_IO2 – Outputs
471-FOE00 ... 474-FOE03 - Function selector, external outputs OE00 ...OE03
Source: Function Selector Output External 0 - 3
Function: Function selectors for external outputs 0 to 3 (I/O module)
The output delivers High level if the condition is met.
Í Functions for outputs on MC6000, page 30
Í Functions for outputs on MC7000, page 32
494-SCTL2 - Control word to set ext. outputs via SIO
Source: Status Control 2
Function: Control word 2 to set the external outputs (I/O module) via serial interface
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
OFF TCAVM OFF – R4W4 REFRC USIGN8
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0 65535 0 R4W4 ALL USIGN16
Bit Hex value Function
0 0001 H Set/reset output OE00
1 0002 H Set/reset output OE01
2 0004 H Set/reset output OE02
3 0008 H Set/reset output OE03
Note:
Output must be assigned with function selector of serial interface:
FOExx = SIO.
