76 • Subject area _SIO – Serial interface RS485 Parameter Description MC6000/7000
_ENCD
_VAL
Index
_VFCON
_PMOD
_KPAD
Contents
Introduction
_SIO
_SCTY
_REF
_SYS
_IO1
_IO2
_CAN
_OPT1
_MOT
_CONF
_TCON
_SCON
_PCON
84-SWDGT - LustBus watchdog time setting
Source: Serial Watchdog Time
Function: Watchdog sampling time of the serial interface
Time in which the Busmaster must have sent at least 1 telegram to the servocontroller. If the
servocontroller does not receive a telegram, error E-WDG (Watchdog) is signaled with error
location 11.
80-SLOAD - LustBus handshake parameter for record transfer
Source:
Function: For handshake see LustBus data transfer protocol.
110-TRACK - Handshake parameter for download of transient memory
Source: TransientAcknowledge
Function: Handshake parameter for download of the transient memory
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
0.00 20.00 0.00 s R4W4 SYSTM FIXPOINT16
Note:
With the setting SWDGT = 0.00 the watchdog is deactivated.
CAUTION - Do not change parameter!
Parameter only for development and service purposes
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
-2 999 0 R6W6 ALL INT16
CAUTION - Do not change parameter!
Parameter only for development and service purposes
Values:
Minimum Maximum Factory set. Unit MODE SMARTCARD Type
02550 – R5W5 ALL USIGN8
