Figure 3.139: Bell Crank
NOTE:
Ensure a minimum clearance of 2–3 mm (1/8 in.) (A) between
the frame and the back of the bell crank lever.
NOTE:
Check the float after levelling the header. For instructions, refer
to Checking and Adjusting Header Float, page 60.
