214323 329 Revision B
5.6.3 CR Feed Deflectors
For New Holland combines only: Short feed deflectors have been factory-installed on the adapter to improve feeding into
the feeder house. They may also have been installed as an option on older machines. Remove the feed deflectors if
necessary. Refer to 6.11.3 Replacing Feed Deflectors on New Holland CR Combines, page 442.
Long feeder kits are provided for narrow feeder house combines and can be installed to replace the short feed deflectors.
Table 5.2 CR Feeder Kits
Combine Model
Feeder House Size Feeder Kit Size
Part Number
CR970, CR9070, CR9080,
CR9090
Wide
Short: 200 mm (7-7/8 in.)
MD #B5405
CR960, CR9060, CR940,
CR9040
Narrow
Long: 325 mm (12-13/16 in.)
MD #B5404
HEADER ATTACHMENT/DETACHMENT
