MacDon FlexDraper FD75 - CA25 Combine Adapter

214323 28 Revision B
2.3.2 CA25 Combine Adapter
Figure 2.3: Header Side of CA25 Combine Adapter
1004589
A
C
D
E
F
F
G
B
B
A - Feed Auger B - Header Float Springs C - Center-Link
D - Hydraulic Reservoir E - Gearbox F - Header Support Arm
G - Feed Draper
Figure 2.4: Combine Side of CA25 Combine Adapter
1004590
A
B
C
D
E
F
H
J
H
G
A - Adapter Gearbox B - Hydraulic Compartment Cover C - Reservoir Oil Level Sight Glass
D - Center-Link E - Header Height Control Indicator F - Transition Frame
G - Torque Wrench H - Header Float Lock J - Side Draper Speed Control
