MacDon FlexDraper FD75 - Reel Endshield Kit; Short Brace Kit for Center Reel Arm

214323 509 Revision B
NOTE:
You must also order additional endshields when converting the reel.
7.2.4 Reel Endshield Kit
The steel shields provided in the Reel Endshield kit attach to the ends of the reels and help to clear material in heavy, hard-
to-cut crops. They are standard equipment on all headers (except nine-bat reels).
1009649
Figure 7.4: Reel Endshields
Hardware and installation instructions are included in the kit.
See your MacDon Dealer for more information.
7.2.5 Short Brace Kit For Center Reel Arm
1004581
Figure 7.5: Short Brace kit (MD #B5605)
The Short Brace kit for Center Reel Arm consists of a set of
shorter braces and necessary hardware for the center reel
support arm. This kit allows you to move the reel farther back
for applications such as straight cutting canola and cutting
shatter prone crops.
Installation and adjustment instructions are included.
MD #B5605
OPTIONS AND ATTACHMENTS
