4.11.3 Setting Sensitivity of Auto Header Height Control – Gleaner
®
R62/R72 Series
Setting the sensitivity of the auto header height control (AHHC) system on the combine affects how quickly the AHHC
system changes the height of the header.
NOTE:
Changes may have been made to combine controls or display since this document was published. Refer to combine
operator’s manual for updates.
1003611
B
A
Figure 4.123: Combine Control Console
1. Engage main threshing clutch (A) and header clutch (B).
1003612
A
Figure 4.124: Throttle
2. Speed throttle (A) to over 2000 rpm.
AUTO HEADER HEIGHT CONTROL
