214323 285 Revision B
1016063
A
B
Figure 4.322: New Holland Combine Display
2. Select FEEDER (A). The FEEDER SETUP page appears.
3. Select MAXIMUM WORK HEIGHT field (B).
1016064
Figure 4.323: New Holland Combine Display
4. Set MAXIMUM WORK HEIGHT to the desired value.
5. Press SET and then press ENTER.
4.20.7 Configuring Reel Fore-Aft, Header Tilt, and Header Type – Some New Holland
CR Series Models
The reel fore-aft, header tilt, and header type functions for the auto header height control (AHHC) system need only be
configured on 2016 New Holland CR models 6.90, 7.90, 8.90, and 9.90.
NOTE:
Changes may have been made to the combine controls or the display since this document was published. Refer to the
combine operator’s manual for updated information.
AUTO HEADER HEIGHT CONTROL
