4.10.4 Adjusting Auto Reel Speed – CLAAS 600 and 700 Series
Reel speed can be set manually or set to change automatically.
NOTE:
Changes may have been made to the combine controls or display since this document was published. Refer to the combine
operator’s manual for updates.
Adjust auto reel speed as follows:
1003736
A
B
Figure 4.117: CLAAS Combine Display, Console, and
Joystick
1. Turn control knob (A) to highlight HEADER/REEL icon (B),
and press control knob (A) to select it. The HEADER/REEL
dialog menu opens.
1010279
B
A
Figure 4.118: CLAAS Combine Display, Console, and
Joystick
2. Turn control knob (A) to select REEL SPEED (B), and adjust
the reel speed (if you are NOT using Auto Reel Speed). A
graph displays in the dialog menu.
