214323 187 Revision B
Figure 4.119: CLAAS Combine Display, Console, and
Joystick
3. Select ACTUAL VALUE (A) from the AUTO REEL SPEED dialog
menu (if you are using Auto Reel Speed). The ACTUAL
VALUE indicates the auto reel speed.
Figure 4.120: CLAAS Combine Display, Console, and
Joystick
4. Use control knob (A) to change the reel speed.
Figure 4.121: Float Indicator
NOTE:
In most cases, ideal ground pressure is one number higher
than value on float indicator with header off ground. For
example, if float indicator pointer (A) is positioned at 0
with header off ground, then ideal ground pressure will be
achieved with pointer positioned at 1. Operating the
header with heavier pressures can wear cutterbar
wearplate prematurely.
AUTO HEADER HEIGHT CONTROL
