MacDon FlexDraper FD75 - Changing Oil Filter

214323 369 Revision B
6.4.4 Changing Oil Filter
Change the oil filter after the first 50 hours of operation and every 250 hours thereafter.
Obtain filter kit MD #320360
41
The kit includes one filter element, one O-ring, and one square-cut gasket. The O-ring
should be used ONLY on CA25 Combine Adapters with Bosch hydraulic manifolds. The square-cut gasket should be used for
all other applications.
DANGER
To prevent bodily injury or death from the unexpected start-up of the machine, always stop the engine and remove the
key from the ignition before leaving the operator’s seat for any reason.
1001163
A
B
Figure 6.32: Adapter Hydraulics Cover
1. Remove five screws (A) and cover (B).
1001164
B
A
Figure 6.33: Hydraulic Manifold and Filter
2. Clean around the mating surfaces of filter (B) and
manifold (A).
3. Remove spin-off filter (B) and clean the exposed filter port
in manifold (A).
MAINTENANCE AND SERVICING
41. Part number MD #202986 is printed on the filter, but service the filter using kit MD #320360. The kit includes
installation instructions.
