214323 517 Revision B
7.5.5 Draper Clips
Draper clips offer additional wear protection for the draper cleats. They may prove useful in situations where conditions
are dry or consistently hot.
Figure 7.18: Draper Clips
Installation instructions are included with the kit.
• MD #294859 for square cleats (A) (for drapers MD #172195, MD #172196, MD #172197, MD #172198)
• MD #294858 for tapered cleats (B) (for drapers MD #220635, MD #220636, MD #220637, MD #220638, MD #220639,
MD #220640)
7.5.6 European Adapter Seal Kit
Figure 7.19: European Adapter Seal Kit
The European Adapter Seal kit encloses the transition area
between the feed draper and side draper near the front of the
header. It also includes side rubber flaps to close off the areas
between the adapter and header.
This kit is NOT recommended for use if rocks are present.
Installation instructions are included in the kit.
MD #B5612
OPTIONS AND ATTACHMENTS
