3.6.3 Optimizing Header for Straight Combining Canola
Ripe canola can be straight cut, but most varieties are susceptible to shelling and seed loss. The recommended settings and
attachments to optimize FD75 FlexDraper
®
Headers for straight cutting canola are provided.
For recommended attachments, refer to 7 Options and Attachments, page 507
The optimization process includes the following modifications to the header:
• Installing a full-length upper cross auger kit
• Installing a European adapter seal kit
• Installing vertical knives
• Installing short center reel braces
• Changing to high-speed auger drive sprocket
• Adding auger fingers. Refer to Table3.3, page 49.
Table 3.3 Auger Finger Quantity
Combine Feeder House Opening
Quantity Installed at
Factory
Optimal Finger Quantity
for Canola
1422–676 mm (56–66 in.)
17
25
1143–1397 mm (45 –55 in.)
17
23
762–1118 mm (30–44 in.)
17 17–19
Recommended settings
Optimizing the header requires adjustments to the following settings:
• Move the reel fore-aft cylinders to the alternate aft location. Refer to Repositioning Fore-Aft Cylinders, page 92.
• Adjust the reel fore-aft position. Refer to Adjusting Reel Fore-Aft Position, page 91.
• Adjust the reel height so the fingers just engage the crop. Refer to 3.7.9 Reel Height, page 89.
• Set the reel cam to position one. Refer to Adjusting Reel Cam, page 99.
• Set the reel speed equal to the ground speed and increase as required. Refer to 3.7.5 Reel Speed, page 85.
• Decrease the feed auger spring tension. Refer to Checking and Adjusting Feed Auger Springs, page 49.
• Set the side draper speed to position 9 on CA25 control. Refer to 3.7.7 Draper Speed, page 87.
Checking and Adjusting Feed Auger Springs
The feed auger has an adjustable spring tensioning system that allows the auger to float on top of the crop instead of
crushing and damaging it. The factory-set tension is adequate for most crop conditions.
DANGER
To prevent bodily injury or death from the unexpected start-up or fall of a raised machine, always stop the engine,
remove the key, and engage the safety props before going under the header for any reason.
1. Raise the header fully.
2. Shut down the engine, and remove the key from the ignition.
3. Engage the header lift cylinder safety props.
