MacDon FlexDraper FD75 - Page 66

214323 48 Revision B
Table 3.2 FD75/CA25 Combine Header Recommended Settings (continued)
Crop Type
Stubble
Height
mm (in.)
Crop
Condition
Divider
Rods
Draper
Speed
Setting
28
Header
Angle
2930
Reel
Cam
Reel
Speed
%
31
Reel
Position
Skid Shoe
Position
30
Stabilizer
Wheels
32
Upper
Cross
Auger
Flax
51–153
(2–6)
Lodged
On 7 D
2
5–10 6 or 7
Down
As required
30
Not
required
Peas
On ground Light
On 7 B – C
2
5–10 6 or 7
Up or middle
Storage
Recom-
mended
Peas
On ground
Normal
On 7 B – C
2
10 6 or 7
Up or middle
Storage
Recom-
mended
Peas
On ground
Heavy
On 7 B – C
2
10 4 or 5
Up or middle
Storage
Recom-
mended
Peas
On ground Lodged
On 7 D
2
5–10
4or5
Up or middle
Storage
Recom-
mended
Lentils
On ground Light
On 8 B – C
2
5–10 6 or 7
Up or middle
Storage
Not
required
Lentils
On ground
Normal
On 7 B – C
2
10 6 or 7
Up or middle
Storage
Not
required
Lentils
On ground
Heavy
On 7 B – C
2
10 6 or 7
Up or middle
Storage
Not
required
Lentils
On ground Lodged
On
7
D
2
5–10 6 or 7
Up or middle
Storage
Not
required
OPERATION
28. Setting on CA25 draper control. 29. Set header angle as shallow as possible (setting A) with center-link and skid shoes while maintaining cutting height. 30. Cutting height is controlled with a combination of skid shoe settings and header angle. 31. Percentage above ground speed. 32. Stabilizer wheels are used to minimize header bouncing and to limit side-to-side movement when cutting off the ground in rolling terrain.
